Watch the video below to explore LKS Airport Kiosk solutions, including check-in, ticketing, and passport scanning features. Learn how our self-service kiosks enhance efficiency, reduce wait times, and improve passenger convenience at airports.
Components | Details | |
PC system | Industrial Board | Seavo/ Gigabyte/Advantech AIMB 562 |
CPU | Dual core E5700/G2020, 2.8ghz; Intel Dual Core I3/I5/I7 | |
RAM | 2GB /4 GB / 8GB | |
HDD | 500G | |
Interface | 6 RS-232 Ports;1 LTP;6 USB Ports,1 10/100M Net Port ;Integrated Net Card, Sound Card | |
PC Power Supply | HUNTKEY/Great Wall | |
LCD monitor | Screen Size | 17 inch/19inch ( optional from 8inch to 65inch) |
Brightness | 250cd/m2 | |
angle | horizontal 100°above;Vertical 80°above | |
Contrast | 1000:1 | |
Backlight tube life | more than 40,000hours | |
Max. resolution | 1280×1024 | |
Touch screen | Screen Size | 17/19 inch Diagonal ( optional from 8inch to 65inch) |
Resolution | 4096x4096 | |
High Transparence, high precision and durability,Orientation precision< 2mm(0.080 inch);pure tempered glass;Single-point touch Life expectancy more 50,000,000 times | ||
Bank/Credit Card Reader | Interface | RS232 |
Card Type | Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card | |
Power Voltage | DC 24V±5% | |
Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal | |
Encrypted Pinpad | Keylift~span | 2,000,000 cycles |
Key force | 2~3N | |
Key trip | >2.5mm | |
Protection level | ip65 | |
Cashcode Bill acceptor | Validation Rate | 96% or higher |
Banknote Insertion | Four-way | |
Escrow | One banknote | |
Capacity | 1000 notes Max | |
Coin Acceptor | Coin Acceptance | Max 32 coin types, in 2*16 or 1*32 channels |
Detection ability of counterfeit Coins | with high detection ability of counterfeit coins | |
Accepting Speed | 2 Coins/Sec | |
Supply Voltage | 10V-16V DC | |
Epson receipt thermal printer | Autocutter | included |
Technology | Thermal printing | |
Paper width | 80mm | |
Printing speed | 150mm/s | |
Data buffer | 4KB | |
Interface | RS232 ,USB | |
UPS | Input voltage | 145-290va |
Output voltage | 200-255va | |
Max time for supplying a single PC | 3~20minutes (for single PC) | |
Digital Power Supply | AC input voltage range | 100~240VAC |
Frequency | 50Hz to 60Hz | |
AC input voltage range | 100~240VAC | |
Frequency | 50Hz to 60Hz | |
Accessories | Wire-lan port, USB ports, speakers, fans, cables, screws, etc. | |
Operation System | Windows 7 or Windows XP operation system without license | |
KIOSK Cabinet | Durable steel frame, Slim and smart design; Easy to install and operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request. | |
Packing | Security Packing method with bubble foam and wooden case |
LKS's Airport Kiosk solutions provide a robust and user-friendly self-service check-in experience, with features designed for airports, offering a range of self-service check in kiosk such as the airport kiosk machine and boarding pass kiosk. These airport kiosks are equipped with dual multifunction touch screens, enabling efficient and seamless passenger check-ins. The airport check-in kiosk supports passport scanning and ticketing with additional options like airport ticket kiosks. Technical specifications include a 17-19 inch high-resolution LCD or TFT touch screen, capable of displaying at 1280x1024 resolution, and enhanced with durable, high-transparency tempered glass for long-lasting performance. The kiosks feature a dual-core CPU, with RAM options from 2GB to 8GB, ensuring high-performance processing. Additional integrated components include RFID card readers, thermal printers for ticket printing, and biometric authentication for secure access. The kiosks also support Windows and Linux operating systems, and they are powered with both 110-240V options, making them versatile for various locations. Our kiosks are also equipped with features such as high-definition advertising screens, passport readers, and optional bill acceptors for added functionality, making them a complete solution for self-service check-in kiosks.
LKS offers a variety of airport kiosks designed to meet the diverse needs of passengers and airport operators. These kiosks provide a self-service, user-friendly experience, improving operational efficiency and reducing wait times. The main types include:
Check-in Kiosk: Facilitates self-check-in, allowing passengers to print boarding passes, check baggage, and confirm flight details quickly and easily.
Boarding Pass Kiosk: Specifically designed for boarding pass printing, enabling passengers to quickly retrieve their boarding passes after check-in or for self-service use.
Self-Service Check-in Kiosk: All-in-one stations for check-in, seat selection, baggage handling, and boarding pass printing, ideal for reducing queues and improving passenger flow.
Airport Ticket Kiosk: Provides ticket purchasing options for a variety of services at the airport, supporting real-time ticket availability and transaction processing.
LKS offers a range of sizes for airport kiosks, allowing for flexible placement and usage across various airport environments. Sizes are customizable to fit different space requirements and passenger needs. The typical size options include:
Small Kiosk (8” to 17” screens): Compact and space-efficient, ideal for smaller airport areas or specialized applications such as mobile ticketing and boarding pass printing.
Medium Kiosk (17” to 19” screens): The most commonly used size for self-check-in kiosks and ticket kiosks, offering a balance between screen visibility and space efficiency.
Large Kiosk (32” to 65” screens): Ideal for high-traffic areas, large-scale check-in or information kiosks, and interactive advertising displays. These kiosks are highly visible and provide an engaging user experience in crowded airport zones.
Customizations and Flexibility
Screen Size and Display: Options from 8” to 65” screens based on the space available and purpose of the kiosk.
Hardware Options: Customizable components such as credit card readers, RFID/NFC card readers, barcode scanners, passport readers, thermal printers, and coin dispensers.
Cabinet Design: Kiosk bodies can be customized in terms of color, materials (steel, aluminum, etc.), and finish (matte, gloss, anti-vandal coating).
Software Customization: Customizable user interfaces, multi-language support, and integration with airport systems for real-time flight information, check-in, and ticketing.
Branding: Kiosk exteriors and interfaces can be branded with company logos and customized designs, making them a perfect fit for any airport or service provider.
Airport Kiosks by LKS are known for their advanced features, durability, and cost-effectiveness. Below are the most popular selling points and advantages that make LKS kiosks a preferred choice for airports worldwide:
Enhanced User Experience
| Multifunctionality
|
Customizable Designs
| Durability and Security
|
High-Quality Hardware
| Flexible Power Options
|
Advanced Software and Integration
| Cost-Effective Solutions
|
24/7 Operational Capability
| Environmental Considerations
|
These selling points make LKS Airport Kiosks a popular choice for airport operators who value user-centric design, durability, flexibility, and cost-efficiency. Whether for check-in, ticketing, or boarding, LKS offers a comprehensive solution that meets the demands of both passengers and airport operators alike.
What did our happy clients say?
I recently purchased the Check-in Kiosk for our airport from LKS, and I couldn't be more pleased. With a 19-inch IR touch screen, dual-core Intel i3 processor, and thermal receipt printer, it has significantly streamlined our check-in process. Highly reliable and easy to operate. We strongly recommend it for any airport looking to improve passenger experience!
We upgraded our airport services with the LKS's Boarding Pass Kiosk, and the results are impressive. The 17-inch capacitive touch screen, combined with a high-quality thermal printer and RFID card reader, ensures fast, smooth boarding. The kiosk is incredibly durable and user-friendly. Highly recommend for any busy airport!
We installed the Ticket Kiosk by LKS at our airport, and it has exceeded expectations. Featuring a 19-inch LCD screen, Intel Core i5 processor, and coin/credit card acceptor, it is perfect for self-service ticketing. The customization options, including logo printing and color schemes, really helped us create a personalized service. Fantastic solution!
After installing the LKS's Self-Service Check-in Kiosk, passengers have experienced faster processing times. The kiosk features a 17-inch TFT screen, industrial-grade components, and a passport reader, ensuring efficiency and security. The ease of maintenance and exceptional customer support make this a must-have for any airport. Highly recommended!
